HK02 Compact Design Solenoid Valve – Brass

Short Description:

COVNA HK02 Brass Solenoid Valve

with compact design. Applied to low pressure system, open from 0 bar. Pressure ranges from 0 to 16 bar. Normally open and normally closed are available. 2 options of materials for choice: Brass and stainless steel. Widely used for ventilator machines and other machines. COVNA produce various solenoid valve in brass, stainless steel and PVC for various application. Consult us to get the best price!

Model

Function: Normally Closed / Normally Open
Pressure: 0 to 16 bar
Voltage: DC-12V, 24V; AC-24V, 120V, 240V/60Hz; 110V, 220V/50Hz
Temperature of Media: -10 to 180℃ (14℉ to 356℉)
Suitable Media: Air, water, steam, oil, gas, etc
Material: Brass

Get A Quick Quote Download Datasheet

Product Detail

Product Tags

Features Of COVNA HK02 Solenoid Valves

● Compact design for various machines like ventilators, and other small equipment

● Responsive

● Applied to low pressure system, open from 0 bar

● Available in G and NPT threaded

Technical Parameters Of COVNA HK02 Solenoid Valves

Port size	1/8", 1/4", 3/8"	Orifice(mm)	1.0, 1.6, 2.5, 3.0, 4.0, 5.0, 6.0
Port Thread	NPT, G	Function	Normally Closed / Normally Open
Pressure	0 to 16 bar	Voltage	DC-12V, 24V; AC-24V, 120V, 240V/60Hz; 110V, 220V/50Hz
Temperature of Media	-10 to 180℃(14℉ to 356℉)	Suitable Media	Water, Air, Oil, Gas, Fuel, Oxygen, etc
Material	Brass or Stainless Steel	Applications	Water treatment, automatic machines, ventilator, etc
