HK08-SF Flange Piston Steam Solenoid Valve
Features Of COVNA HK08-F Steam Solenoid Valves
● Piston construction with high frequency which could withstand high-temperature range
● Flange connection with features including easy to install and large sizes up to 4"
● Applied to the applications which have high-temperature needs
Technical Parameters Of COVNA HK08-F Steam Solenoid Valves
Port size | 3/8", 1/2", 3/4", 1", 1.2", 1.5", 2" | Orifice(mm) | 12, 15, 20, 25, 32, 40, 50 |
Port Thread | Flange | Function | Normally Closed / Normally Open |
Pressure | 0.3 to 16bar / 0.3 to 25bar | Voltage | DC-12V, 24V; AC-24V, 120V, 240V/60Hz; 110V, 220V/50Hz |
Temperature of Media | -10 to 180℃ (14℉ to 356℉) | Suitable Media | Hot water, hot oil, steam, etc |
Material | Stainless Steel | Applications | Boiler, steam pipeline, etc |
