HK60-Q-F-I Modulating Electric Actuated Ball Valve

Short Description:

Manufacturer of

HK60-Q-F-I Modulating Electric Actuated Ball Valve

with modulating electric actuator. Available in remote control to achieve the goal of industrial automation. Available in 4-20mA, 0-10V DC or 1-5V DC signal controls. Widely used for irrigation system, wastewater treatment, etc.
COVNA will help you to choose the right electric actuated ball valve and suitable control method basic on your project.
Contact us to get a free valve solution!

Model

Actuator Type:Intelligent Type
Body Material:Stainless Steel
Pressure:1.0 / 1.6 / 2.0 / 6.4 MPa
Temperature Of Media:-10~180℃
Suitable Media:Water, Air, Oil, Gas, etc
Voltage:DC-12V, 24V; AC-24V, 120V, 240V/60Hz; 110V, 220V/50Hz
Connection Type:Flanged

Get A Quick Quote Download Datasheet

Product Detail

Product Tags

● Equipped with modualting type or intelligent type electric actuator to allow automation more easier

● Available in manual control, signal control and AC/DC power supply

● Available in stainless steel 304 and 316 material

Size Range	DN15-200	Body Material	Stainless Steel
Core Materal	Stainless Steel, WCB	End Connection	Flange
Working Pressure	1.0 / 1.6 / 2.0 / 6.4 MPa(10 / 16 / 20 / 64 bar)	Suitable Media	Water, Air, Oil, Gas, etc
Temperature Of Media	-10~180℃ (14℉~356℉)	Structure	Straight Through Flow Path
Voltage	DC-12V, 24V; AC-24V, 120V, 240V/60Hz; 110V, 220V/50Hz	Voltage Tolerance	±10%

ON/OFF Type	Feedback: the active contact signal, passive contact signal, resistant, 4-20mA
Regulation Type	Input & Output signal: DC 4-20mA, DC 0-10V, DC 1-5V
Intelligent Type	Input & Output signal: DC 4-20mA, DC 0-10V, DC 1-5V
Field Operation	The field, remote control switch regulation and MODBUS, PROFIBUS field bus
Voltage optional	AC 110-240V 380V 50/60Hz; DC12V, DC24V, Special voltage can be customized
Protection Class	IP65
