QT Series Explosion Proof Electric Actuator

Short Description:

Explosion Proof Electric Actuator

has a good sealing performance. Widely used in gas industry, LPG industry and so on. Using 110V/220V/380V AC as supply power. With manual override. Manual control in case of power failure.
Manufacturing explosion-proof electric actuator with 270-degree rotation. For your oil & gas, or fire industry actuation solution.
Consult us to get the best price!

Model

Supply Power: 3PH: AC380V、AC415V、AC440V; ±10% 50/60Hz; 1PH: AC110V、AC220V、AC24V; ±10% 50/60Hz; DC: DC24V(±10%)
Basic Error: 2.5%
Outdoor Protection Class: IP65
Temperature: -20℃ to 60℃
Height Above Sea Level: ≤1000m
Humidity: ≤90% (25℃)
Model: QT Series

Get A Quick Quote Download Datasheet

Product Detail

Product Tags

Benefits Of Explosion-proof Electric Valve Actuator:

The COVNA Exd II CT4 electric explosion-proof actuator is equipped with an explosion-proof module, which can effectively enhance the explosion-proof performance of the electric actuator and improve the safety of the project. Industrial automation is achieved by receiving or feeding back signals. It is widely used in oil and gas, metallurgy, mining and other dangerous industries to ensure the personal safety of personnel.

Description:

● The actuators can be either remotely controlled or locally controlled. They are widely used in the fields such as oil, chemistry, power generation, water treatment, paper making.

● The protection class is IP65, and the explosion proof class is Exd II CT4
